Z-Wave Smart Thermostat

Simplify your life – enjoy the benefits of seamless integration with home security controls and home automation gateways.

The TBZ500 is a smart Z-Wave® thermostat that pairs with major security panels, remote management applications and smart hubs within a Z-Wave® ecosystem. The TBZ500 thermostat is easy to install and can replace any existing wired or battery powered thermostat.

View Support Page

FREQUENTLY ASKED QUESTIONS

What is included in the thermostat package?

The Z-Wave Smart Thermostat package includes:

  • 1 x TBZ-500 Thermostat
  • 1 x Wall Mount Plate
  • 2 x Mounting Screws (#6 x 3/4)
  • 2 x Screw Anchor
  • 1 x Z-Wave Smart Start Label (DSK code)
  • 4 x AA batteries
  • 1 x Installation Manual
Is my HVAC system compatible?

Please try the compatibility checker to identify compatibility entering old thermostat wiring.

It supports:

  • Standard Gas/Electric HVAC Systems: 2-stage heating, 2-stage cooling
  • Heat Pump HVAC Systems: 3-stage heating, 2-stage cooling.
What batteries does the thermostat use?

The thermostat uses Four (4) AA batteries.

What protocol does the thermostat support?

The thermostat is a Z-Wave Plus compliant device that can participate in any standard Z-Wave Plus network.

Is my Z-Wave security panel or gateway compatible?

TBZ-500 is certified Z-Wave Plus with S2 Security. It works with any Z-Wave certified panel. It has been tested with Honeywell Lynx Touch 5200/7000/Vista20p + VAM/Vista 128BPT + Tuxedo Touch, Qolsys IQ/IQ2, 2GIG GC2/GC3/GC2e/GC3e, Interlogix Simon XT/XTi5 and Samsung SmartThings Hub.

What is the ordering part number?

TBZ500W
TBZ500B

Features

  • Z-Wave Plus® Certified, S2 Security
  • FW update via Z-Wave® OTA
  • Standard gas/electric HVAC Systems: 2-stage heating, 2-stage cooling
  • Heat Pump HVAC Systems: 3-stage heating, 2-stage cooling
  • Fan system: Selectable for gas or electric heat systems
  • Heat Pump Change Over Valve (reversing valve): Selectable for change over with heat or change over with cool (O or B output)
  • Emergency Heat: In Heat Pump Mode, Emergency Heat Mode is selectable from the thermostat
  • Compressor short cycle protection delay of 5 minutes (adjustable)
  • Backlit fixed 128 segment B/W LCD with 7-character message bar

Part Numbers

  • TBZ500W
  • TBZ500B

Compliance

  • USA: FCC Compliant to CFR47, Part 15B
  • Canada: Industry Canada RSS 210, Issue 8



VISIT OUR SUPPORT PAGE

Product Manual
Installation Manual
